1. Extremely high pixel density;
2. Black LED, phenomenal contrast ratio of 5000:1;
3. Aluminum cabinet design, light weight and high precision;
4. Vibrant images with uniform colors;
5. Extra wide viewing angle.
Parameter | Value |
Pixel Pitch | 2.5mm |
Pixel configuration | 1R1G1B |
LED type | 3-in-1 SMD2121 |
Brightness | 800 cd/m² |
Color temperature | 6500K |
Viewing angle | H: 160°; V:160° |
Pixel density | 160000 pixels/m² |
Recommended viewing distance | ≥2.5 M |
Module size | 160mm×160mm |
Cabinet size | W480mm×H480mm×D90mm |
Weight | 10.5 kg/panel |
Area | 0.2304 m² |
Material | Die-casting Aluminum |
Aspect ratio | 1:1 |
Ingress protection | IP30 |
Operating Temperature/Humidity | 0℃~+45℃/10~90%RH |
Storage Temperature/Humidity | -10℃~+55℃/10~90%RH |
Pixels per panel | 192×192 Dots |
Gray scale | 16 bits |
Processing depth | 65536 levels per color |
Color | 281.4 trillion |
Brightness control | Manual/Automatic |
Contrast ratio | 5000:1 |
Video frame rate | 50/60 Hz |
Rate refresh | ≥3200 Hz |
Input voltage | 110~240VAC |
Input power frequency | 50~60 Hz |
Input power <max> | 170W/panel |
Input power <typical> | 57W/panel |
Life Time | ≥100,000 Hours |
LED Wavelength | R:620~630nm G:520~535nm B:465~475nm |
Driving Method | 1/16 Scan, Constant Current |
Input signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
Rigging form | Hanging/Fixed with support bracket |
Data interconnection | CAT5 Cable ( L≤140m )；multi-mode fiber ) ( L≤500m )；single mode fiber ( L≤20km ) |
Note: The power is reference，specification subjected to change without prior notice. |
